Technical Data:

a) Forming Product Specification:

  1. Diameter: ��400 mm fibre reinforced resin grinding wheel.

  2. Thickness: 1.0 ~ 6.0 mm.

  3. Aperture: As design drawing supply by buyer.

b) Structure: 16 mould,push type. Including moulded cover board transit system.

c) The Pressure of Four-column Presses: 400 MT;

d) Moulding Methods: Auto scale material,Auto Feeding,Constant Pressure Moulding.

e) Mould Rotation Speed: 70 ~ 80 rpm.

f) Working Speed: 1800 - 2400 pcs/08hours;

g) Operator: 03 persons;

h) Main Components of PLC Use MITSUBISHI Products.
